Place of Origin:
Hefei,China
Brand Name:
Grande
Certification:
CE
Model Number:
PK-306
Contact Us
The flat pack feature allows for easy transportation, making them suitable for remote or hard-to-reach locations.
Basic Info
| Quick Installation Prefabricated House Parameter | |||
| Part Name | Standard sizes | Quantity | |
| Standard | 5800mm*2500mm*2490mm | 1 | |
| Frame(2.3~2.5mm) | Top frame | 2.3mm galvanized forming beam, galvanized content 80g/㎡, 150mm wide and 5500mm long | 2 |
| 2.3mm galvanized forming beam, galvanized content 80g/㎡, 150mm wide and 2194mm long | 2 | ||
| Galvanized 30mm*50mm*1.2mm cross brace, galvanized content 80g/㎡ | 5 | ||
| 20mm*30mm*1.2mm galvanized square tube, galvanized content 80g/㎡ | 6 | ||
| 20mm*20mm*1.0mm galvanized square tube, galvanized content 80g/㎡ | 2 | ||
| 20mm*10mm*1.0mm galvanized square tube, galvanized content 80g/㎡ | 2 | ||
| 0.3mm 831 ceiling tile | 18 | ||
| 75mm rolled cotton insulation | 18 | ||
| Type 50 hanging rail, 5595mm, galvanized content 80g/㎡ | 2 | ||
| hanging wheel | 4 | ||
| connector | 8 | ||
| Bottom frame | 2.5mm galvanized forming beam, galvanized content 80g/㎡, 150mm wide and 5800mm long | 2 | |
| 2.5mm galvanized forming beam, galvanized content 80g/㎡, 150mm wide and 2494mm long | 2 | ||
| Lower beam angle steel folded parts, 5800mm | 2 | ||
| Lower beam angle steel folded parts, 2494mm | 2 | ||
| Galvanized square tube 40mm*60mm*1.7mm galvanized cross brace, galvanized content 80g/㎡ | 11 | ||
| Upright column | 2.3mm galvanized column, galvanized content 80g/㎡ 150 wide, 150 wide and 2195mm high | 4 | |
| Connector 8.0mm, galvanized content 80g/㎡ | 8 | ||
| Galvanized corner fittings | 3.0mm upper corner piece, galvanized content 80g/㎡ 150mm*150mm*140mm | 4 | |
| 3.0mm lower corner fittings, galvanized content 80g/㎡ 150mm*150mm*150mm | 4 | ||
| External roof | Skin roof 0.4mm color steel single tile, vaulted roof, drainage around | 1 | |
| 0.47mm color steel single tile, corrugated tile vault, special waterproof method | 1 | ||
| Moisture-proof film | PE resin film 1.0mm | 1 | |
| Paint | Electrostatic spray | 1 | |
| Bolt | inner hexagon | 24 | |
| Downspouts | 50 downspout | 4 | |
| Special Z-shaped parts | 0.8mm Z-shaped fixed ceiling tile | 4 | |
| Cement Fiber Board/Glass Magnesium Board | 16mm thick, 2440mm*1120mm | 5 | |
| Floor | 1.6mm, floor leather | 1 | |
| Door | Steel door | 920mm*2030mm steel door (950 wall panel) | 1 |
| Angular line | Color steel or pvc internal angle line | 4 | |
| Plastic steel anti-theft window | 950mm*1200mm single glass double push (950 type wall panel) | 2 | |
| Auxiliary material | Screws, sealant, internal box connections | 1 | |
| Electrical System | Distribution box J-6 (1), 1 leak protection (32A), 2 five-hole 10A, 1 switch, 1 three-hole 16A, 2 strip purification lamps | 1 | |
| Wall panel | 1150 type (H port) | 50mm rock wool board, double-sided iron sheet 0.3mm, bulk density 50kg/m³ |
1 |
PRODUCT COMPARISON
FAQ
Q: How long does it take to assemble a Flat Pack Prefab House? A: The assembly time for a Flat Pack Prefab House depends on various factors such as the size and complexity of the design. However, on average, it can be assembled within a few weeks to a couple of months, significantly faster than traditional construction methods.
Q: Can I customize the layout and design of the Flat Pack Prefab House? A: Absolutely! The Flat Pack Prefab House offers a modular design that allows for easy customization. You can work with our design team to personalize the layout, room configurations, and choose from a range of finishes and materials to create a home that suits your unique preferences and needs.
Q: Can I transport the Flat Pack Prefab House to a different location? A: Yes, one of the key advantages of the Flat Pack Prefab House is its portability. The house can be easily disassembled and transported to a new location, making it a convenient option for those who require a flexible and mobile housing solution.
Q: Are Flat Pack Prefab Houses durable? A: Absolutely. Flat Pack Prefab Houses are constructed using high-quality materials that are known for their durability and strength. They are designed to withstand various weather conditions and provide long-lasting performance, ensuring a stable and reliable living space.
Q: Are Flat Pack Prefab Houses energy-efficient? A: Yes, energy efficiency is an important consideration in the design of Flat Pack Prefab Houses. They can be equipped with insulation materials to regulate temperature, reducing the need for excessive heating or cooling. Additionally, energy-efficient fixtures and appliances can be installed to further minimize energy consumption and lower utility costs.
Q: Can Flat Pack Prefab Houses be expanded in the future? A: Absolutely. One of the advantages of Flat Pack Prefab Houses is their expandability. Whether you need additional rooms or want to enlarge the existing living space, the modular design allows for easy expansion and customization to accommodate future growth or changing needs.
Q: Are Flat Pack Prefab Houses environmentally friendly? A: Yes, sustainability is a key aspect of Flat Pack Prefab Houses. They are designed to minimize waste during construction and promote eco-friendly practices. By utilizing energy-efficient features and incorporating environmentally conscious materials, they offer a greener housing solution compared to traditional construction methods.
Q: Are Flat Pack Prefab Houses suitable for year-round living? A: Absolutely. Flat Pack Prefab Houses are designed to provide comfortable year-round living. With proper insulation, ventilation, and heating/cooling systems, they can offer a cozy and pleasant living environment in all seasons.
Q: Can Flat Pack Prefab Houses be used for commercial purposes? A: Yes, Flat Pack Prefab Houses are versatile and can be utilized for various applications, including commercial purposes. They can be transformed into offices, retail spaces, classrooms, or other commercial establishments, providing a flexible and efficient solution for business needs.
Q: Are there any warranty options available for Flat Pack Prefab Houses? A: Yes, we provide warranty options for our Flat Pack Prefab Houses. The specific details and coverage may vary, so please refer to the product documentation or contact our customer support for more information on the available warranty options.
